Building a cloud-native satellite imagery pipeline

Anthony Lukach

OSGeo Calgary - Jan 2020

About DevSeed

We solve the world's hardest problems with open data and open technology.

We're hiring!

https://developmentseed.org/careers/jobs/

SmallSat

SmallSat is part of the "Commercial Smallsat Data Acquisition Program" (CSDA) .

What:

The Commercial Smallsat Data Acquisition Program (CSDAP) objective is to identify, evaluate, and acquire data from commercial sources that support NASA’s Earth science research and application activities directly related or leading to Essential Climate Variables (ECVs) focused on the atmosphere, cryosphere, land, and ocean as defined by the Global Climate Observing System.

https://earthdata.nasa.gov/esds/small-satellite-data-buy-program

Why:

Commercially acquired data may provide a cost-effective means to augment and/or complement the suite of Earth Observations acquired by NASA and other US government agencies and those by international partners and agencies. Emphasis is placed on data acquired by small-satellite constellations, affording the means of complementing NASA acquired data with higher resolutions, increased temporal frequency, or other novel capabilities in support of existing Earth science and application activities.

https://earthdata.nasa.gov/esds/small-satellite-data-buy-program

How it will be used:

Future Research Opportunities in Space and Earth Science (ROSES) solicitations will include commercial data use elements for utilization of mirrored data. A search, discovery, and download system is being built for broader dissemination of acquired data.

https://earthdata.nasa.gov/esds/small-satellite-data-buy-program

Trivia:

A "small" satellite is anything under 500 kilograms. source

(1100 lbs)

(☝️ 700 kilograms)

Summary of Needs

  1. Database to keep track of ingested data
  2. Frontend for users to explore data holdings
  3. Place orders to populate the system
  4. Data pipeline to ingest data

Immediate focus

Full-vertical of application

➕

Situation

  • NASA had pre-purchased 500M sq km of satellite imagery.
  • About 25M (5%) of it was used.
  • Needed to use up the rest of the quota by end of contract (3 months away, Dec 2019)

Plan

  • Reingest all already purchased data
  • Place new orders requested by NASA scientists

Data Catalogue

Goal: Catalog our holdings so that it can be discovered

A user should be able to query for ingested satellite imagery that was captured...

  • within a given time range
  • within a given area of interest
  • with particular sensors
  • under a certain percentage of cloud cover

Solution:
STAC Spec

Our implementation:
sat-api-pg

https://github.com/developmentseed/sat-api-pg/

Frontend

Goal: Explore data

How to order all this data

Data Pipeline

Cloud Native design goals

  • Take advantage of cloud-provided solutions for reduced complexity
  • Massively scalable
  • Pay per use

Event Driven Architecture

  • Reacting to changes in the system

Serverless Computing

  • Pay per use
  • Letting cloud provider handle provisioning and managing resources

Ingestion Workflow

  1. Triggered on delivery of manifest.json file within our inbox/:provider folder.
  2. Parse manifest.json, get list of all files to be delivered.
  3. Poll for all files (with backoff)
  4. Parse metadata.json, generate STAC item
  5. Download thumbnail to our bucket, update STAC item
  6. Copy assets to storage "folder", update STAC item
  7. Submit STAC item to our STAC API

Enter: AWS Step Functions

Demo

metadata.json + manifest.json = STAC Item

metadata.json

{
  "id": "1004515_3755807_2017-12-21_1003",
  "type": "Feature",
  "geometry": {
    "coordinates": [
      [
        [
          37.08068412556186,
          36.196897942636234
        ],
        [
          37.10136932148183,
          36.27557769311144
        ],
        [
          37.132354200017566,
          36.39139330067675
        ],
        [
          37.13694614185042,
          36.19783301055067
        ],
        [
          37.08068412556186,
          36.196897942636234
        ]
      ]
    ],
    "type": "Polygon"
  },
  "properties": {
    "acquired": "2017-12-21T07:36:59.767307Z",
    "anomalous_pixels": 0.04,
    "black_fill": 0.92,
    "cloud_cover": 0.038,
    "columns": 8000,
    "epsg_code": 32637,
    "grid_cell": "3755807",
    "ground_control": true,
    "gsd": 3.9,
    "item_type": "PSOrthoTile",
    "origin_x": 307500,
    "origin_y": 4032500,
    "pixel_resolution": 3.125,
    "provider": "planetscope",
    "published": "2017-12-21T20:41:57.000Z",
    "rows": 8000,
    "satellite_id": "1003",
    "strip_id": "1004515",
    "sun_azimuth": 151.7,
    "sun_elevation": 24.6,
    "updated": "2017-12-22T00:51:24.000Z",
    "usable_data": 0.05,
    "view_angle": 1
  }
}
manifest.json

{
  "item_id": "1004515_3755807_2017-12-21_1003",
  "item_type": "PSOrthoTile",
  "assets": {
    "json_metadata": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/1004515_3755807_2017-12-21_1003_metadata.json",
      "media_type": "application/json",
      "size": 1144,
      "digests": {
        "md5": "5f76d57369dbfdfb323eeed76b68ad85",
        "sha256": "cceaf96b98950c256c3484eba741c132aed70c0322e07d9341eeb766015ebd6f"
      },
      "annotations": {
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "basic_analytic": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS.tif",
      "media_type": "image/tiff",
      "size": 101477936,
      "digests": {
        "md5": "d3ce78b99692829c7c1c6a57fe92eb5d",
        "sha256": "4ca208cee9e4f59745e9723a210726f305eccc522f260172ef8da72c5f4f4e19"
      },
      "annotations": {
        "planet/asset_type": "basic_analytic",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "basic_analytic_dn": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_DN.tif",
      "media_type": "image/tiff",
      "size": 61534618,
      "digests": {
        "md5": "2b0f204c0ab450b5d9b2702e67880014",
        "sha256": "8cf8a918014ccad1fa722204e67376e5b3d53a7c44f4de4539721ff8277ef523"
      },
      "annotations": {
        "planet/asset_type": "basic_analytic_dn",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "basic_analytic_dn_xml": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_DN_metadata.xml",
      "media_type": "text/xml",
      "size": 8911,
      "digests": {
        "md5": "173d5e644964a40e55371745078d7557",
        "sha256": "d7f444d5e36a2f20c729e2b1672707305dfdc851b751a1cd63cc49de42dc3e0d"
      },
      "annotations": {
        "planet/asset_type": "basic_analytic_dn_xml",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "basic_udm": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_DN_udm.tif",
      "media_type": "image/tiff",
      "size": 422678,
      "digests": {
        "md5": "87ef5be6288b24e093e74d6aa5e735a4",
        "sha256": "a6767f790c9f23af095ad4f7be4a68031d55a70df2091bd1c4ff4f00bc29a8cd"
      },
      "annotations": {
        "planet/asset_type": "basic_udm",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "basic_analytic_rpc": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_RPC.TXT",
      "media_type": "text/plain",
      "size": 3357,
      "digests": {
        "md5": "da6dad1174ca6e4b0ac836e1644df9f5",
        "sha256": "e692b73436f8f20718d064826b9f4315f07a960300dba5f443c3dedfed657c5e"
      },
      "annotations": {
        "planet/asset_type": "basic_analytic_rpc",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "basic_analytic_xml": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_metadata.xml",
      "media_type": "text/xml",
      "size": 10264,
      "digests": {
        "md5": "c6a236fec4b6f3449b64b309bf2dada4",
        "sha256": "222eb857db75f9de6b37566f6fb6442de39d76ce81edcc15746bed7b34c71d22"
      },
      "annotations": {
        "planet/asset_type": "basic_analytic_xml",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "analytic": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS.tif",
      "media_type": "image/tiff",
      "size": 167354952,
      "digests": {
        "md5": "e934d9993282347eab6fddeca5c4f919",
        "sha256": "aa9f2b888b40f0a2adf9123229101377d35acbd304b00fd8c3cfd2b723ea5d1b"
      },
      "annotations": {
        "planet/asset_type": "analytic",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "analytic_dn": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_DN.tif",
      "media_type": "image/tiff",
      "size": 95645466,
      "digests": {
        "md5": "d486d67fdfc669dbcfcbe08d380a8ac9",
        "sha256": "374634b98bb97cc122b9c492d1161bf69e1bffba47023b04e268073980fcc29b"
      },
      "annotations": {
        "planet/asset_type": "analytic_dn",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "analytic_dn_xml": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_DN_metadata.xml",
      "media_type": "text/xml",
      "size": 9041,
      "digests": {
        "md5": "2e6f94893501e0b5d4d98c4b52ae87ad",
        "sha256": "c33d7693291829dead2552dc7667b8de8715f4a0f07dfa69cd444fdfa2e4b984"
      },
      "annotations": {
        "planet/asset_type": "analytic_dn_xml",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "udm": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_DN_udm.tif",
      "media_type": "image/tiff",
      "size": 1062467,
      "digests": {
        "md5": "e89ce63e0740f9dafbdd7f59bcb96b0a",
        "sha256": "735a26d8ce2596fee2691f3291555d1ce23c2f973234b4eee6b9f5a513d5a0ab"
      },
      "annotations": {
        "planet/asset_type": "udm",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "analytic_sr": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_SR.tif",
      "media_type": "image/tiff",
      "size": 143125176,
      "digests": {
        "md5": "8d61256d2a0833e6e6378697e645c40d",
        "sha256": "273c07190d3d947f7f4da580fa9eff11133af4fa9a96842b66af66fd41edcfc4"
      },
      "annotations": {
        "planet/asset_type": "analytic_sr",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    },
    "analytic_xml": {
      "path": "files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_metadata.xml",
      "media_type": "text/xml",
      "size": 10394,
      "digests": {
        "md5": "4c16c0b5cec9b49b83eee180e8454846",
        "sha256": "bd207bb312f42a2f9a47aba8c4aeafc86095a11b1b235d2e82e465c0f09b5481"
      },
      "annotations": {
        "planet/asset_type": "analytic_xml",
        "planet/bundle_type": "all",
        "planet/item_id": "1004515_3755807_2017-12-21_1003",
        "planet/item_type": "PSOrthoTile"
      }
    }
  },
  "bundle_type": "all"
}
STAC Output

{
  "id": "PSOrthoTile-1004515_3755807_2017-12-21_1003",
  "type": "Feature",
  "geometry": {
    "coordinates": [
      [
        [
          37.08068412556186,
          36.196897942636234
        ],
        [
          37.10136932148183,
          36.27557769311144
        ],
        [
          37.132354200017566,
          36.39139330067675
        ],
        [
          37.13694614185042,
          36.19783301055067
        ],
        [
          37.08068412556186,
          36.196897942636234
        ]
      ]
    ],
    "type": "Polygon"
  },
  "bbox": [
    37.08068412556186,
    36.196897942636234,
    37.13694614185042,
    36.196897942636234
  ],
  "properties": {
    "datetime": "2017-12-21T07:36:59.767307Z",
    "eo:gsd": 3.9,
    "eo:epsg": 32637,
    "eo:cloud_cover": 3,
    "eo:off_nadir": 1,
    "eo:sun_azimuth": 151.7,
    "eo:sun_elevation": 24.6,
    "pl:anomalous_pixels": 0.04,
    "pl:black_fill": 0.92,
    "pl:columns": 8000,
    "pl:grid_cell": "3755807",
    "pl:ground_control": true,
    "pl:item_type": "PSOrthoTile",
    "pl:origin_x": 307500,
    "pl:origin_y": 4032500,
    "pl:pixel_resolution": 3.125,
    "pl:provider": "planetscope",
    "pl:published": "2017-12-21T20:41:57.000Z",
    "pl:rows": 8000,
    "pl:satellite_id": "1003",
    "pl:strip_id": "1004515",
    "pl:updated": "2017-12-22T00:51:24.000Z",
    "pl:usable_data": 0.05,
    "eo:bands": []
  },
  "links": [],
  "assets": {
    "thumbnail": {
      "href": "https://tiles.planet.com/data/v1/item-types/PSOrthoTile/items/1004515_3755807_2017-12-21_1003/thumb",
      "title": "Thumbnail",
      "status": "active"
    },
    "json_metadata": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/1004515_3755807_2017-12-21_1003_metadata.json",
      "title": "json_metadata",
      "type": "application/json",
      "md5_digest": "5f76d57369dbfdfb323eeed76b68ad85",
      "size": 1144
    },
    "basic_analytic": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS.tif",
      "title": "basic_analytic",
      "type": "image/tiff",
      "md5_digest": "d3ce78b99692829c7c1c6a57fe92eb5d",
      "size": 101477936
    },
    "basic_analytic_dn": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_DN.tif",
      "title": "basic_analytic_dn",
      "type": "image/tiff",
      "md5_digest": "2b0f204c0ab450b5d9b2702e67880014",
      "size": 61534618
    },
    "basic_analytic_dn_xml": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_DN_metadata.xml",
      "title": "basic_analytic_dn_xml",
      "type": "text/xml",
      "md5_digest": "173d5e644964a40e55371745078d7557",
      "size": 8911
    },
    "basic_udm": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_DN_udm.tif",
      "title": "basic_udm",
      "type": "image/tiff",
      "md5_digest": "87ef5be6288b24e093e74d6aa5e735a4",
      "size": 422678
    },
    "basic_analytic_rpc": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_RPC.TXT",
      "title": "basic_analytic_rpc",
      "type": "text/plain",
      "md5_digest": "da6dad1174ca6e4b0ac836e1644df9f5",
      "size": 3357
    },
    "basic_analytic_xml": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_1B_AnalyticMS_metadata.xml",
      "title": "basic_analytic_xml",
      "type": "text/xml",
      "md5_digest": "c6a236fec4b6f3449b64b309bf2dada4",
      "size": 10264
    },
    "analytic": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS.tif",
      "title": "analytic",
      "type": "image/tiff",
      "md5_digest": "e934d9993282347eab6fddeca5c4f919",
      "size": 167354952
    },
    "analytic_dn": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_DN.tif",
      "title": "analytic_dn",
      "type": "image/tiff",
      "md5_digest": "d486d67fdfc669dbcfcbe08d380a8ac9",
      "size": 95645466
    },
    "analytic_dn_xml": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_DN_metadata.xml",
      "title": "analytic_dn_xml",
      "type": "text/xml",
      "md5_digest": "2e6f94893501e0b5d4d98c4b52ae87ad",
      "size": 9041
    },
    "udm": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_DN_udm.tif",
      "title": "udm",
      "type": "image/tiff",
      "md5_digest": "e89ce63e0740f9dafbdd7f59bcb96b0a",
      "size": 1062467
    },
    "analytic_sr": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_SR.tif",
      "title": "analytic_sr",
      "type": "image/tiff",
      "md5_digest": "8d61256d2a0833e6e6378697e645c40d",
      "size": 143125176
    },
    "analytic_xml": {
      "href": "s3://my_bucket/storage/files/PSOrthoTile/1004515_3755807_2017-12-21_1003/all/1004515_3755807_2017-12-21_1003_3B_AnalyticMS_metadata.xml",
      "title": "analytic_xml",
      "type": "text/xml",
      "md5_digest": "4c16c0b5cec9b49b83eee180e8454846",
      "size": 10394
    }
  },
  "collection": "planet"
}

Thanks!

  • twitter/anthonylukach
  • github/alukach
